S8vk Omron Smps Power Supply, Input Voltage: 230vac, Output Voltage: 24V

Get a Price/Quote

S8vk Omron Smps Power Supply, Input Voltage: 230vac, Output Voltage: 24V Specification

Theory
Switching Power Supply

Mounting Type
DIN Rail, Panel Mountable

Frequency
50/60Hz

Noise Level
Low

Features
High Reliability, Compact Size, Wide Input Range

Voltage
Input: 230VAC, Output: 24VDC

Working Temperature
-25C to +60C

Inlet/Outlet
Terminal Block Connectors

Material
Metal Casing

Structure
Enclosed Type

Power
60W / 120W / 240W / 480W (model dependent)

Standard
IEC 60950-1, UL508, EN50178

Fuel Type
Electric

Usage
Industrial Automation, Control Panels

Application
SMPS for Industrial Equipment

Capacity
Depends on Output Power (current rating varies with model)

Ripple & Noise
120mVp-p

Protection Functions
Overcurrent, Overvoltage, Short Circuit, Overtemperature

Cooling Method
Natural Air Cooling

Insulation Resistance
100M min. (at 500VDC)

Output Current
2.5A / 5A / 10A / 20A

Adjustment Range
22 - 28VDC (output voltage trimmed)

Model Series
S8VK-G Series

Efficiency
Up to 91%

Weight
Approx. 330g to 1.2kg depending on model

Dimensions
Varies by model (e.g. 32 x 124 x 102 mm for 60W)

Enclosure Rating
IP20

About S8vk Omron Smps Power Supply, Input Voltage: 230vac, Output Voltage: 24V

Omron has developed a new and exciting family of compact power supplies. With the same high quality and practical design that made our previous series safe, reliable, and easy to install, the new S8VK series is even tougher, more compact and easier to use. Omron is a world leader in the development and manufacture of industrial power supplies.

High Performance for Industrial Automation

Designed for industrial automation and control panels, the S8VK-G Series offers robust, efficient, and reliable power delivery. With a wide power range and multiple current options, it supports diverse applications from small machinery to large-scale equipment, meeting demanding requirements in production environments.

Superior Protection and Safety Features

The power supply integrates advanced protection mechanisms, including overcurrent, overvoltage, short circuit, and overtemperature safeguards. Certified to IEC 60950-1, UL508, and EN50178 standards, it ensures operational safety and longevity even under challenging conditions.

Flexible Installation and User-Friendly Operation

Offered in a compact, metal-enclosed structure, the S8VK-G Series supports both DIN rail and panel mounting. Terminal block connectors simplify wiring, while the adjustable voltage output allows for precise tuning to application needs. Its wide operating temperature range ensures adaptability across varied environments.

FAQ's of S8vk Omron Smps Power Supply, Input Voltage: 230vac, Output Voltage: 24V:

Q: How does the Omron S8VK-G Series ensure protection against electrical faults?

A: The S8VK-G Series includes multiple protection functions such as overcurrent, overvoltage, short circuit, and overtemperature protection. These features help safeguard connected equipment and the power supply itself by automatically shutting down or limiting output during abnormal conditions.

Q: What applications are best suited for the S8VK-G SMPS power supply?

A: This series is ideal for industrial automation applications, such as control panels, factory equipment, and process machinery. Its high reliability and compact size make it suitable for demanding environments where stable and efficient power is critical.

Q: Where can the S8VK-G Series be mounted?

A: The power supply is designed for both DIN rail and panel mounting, providing versatile installation options to fit various industrial setups and enclosure types.

Q: What is the process for adjusting the output voltage?

A: Users can trim the output voltage within the 22-28VDC range by using the adjustment knob located on the unit, enabling fine-tuning to meet the specific voltage requirements of connected devices.

Q: When should I consider using the higher output current models (5A, 10A, or 20A)?

A: Choose higher output current models when powering devices or systems with elevated power demands, such as motor drives, PLCs, or multi-device control panels, to ensure adequate and stable power delivery.

Q: What are the benefits of natural air cooling in the S8VK-G power supply?

A: Natural air cooling reduces the need for additional cooling systems, lowers noise levels, and minimizes maintenance. This enhances system reliability and contributes to the power supply's long operational life.

Q: How does the S8VK-G Series meet international standards?

A: The power supplies comply with IEC 60950-1, UL508, and EN50178 standards, ensuring high safety, quality, and compatibility with industrial practices worldwide.
